Cornelius C10 - C20 Spare Parts List (Models 06 1 050101;102;201)

11
®
C10/C20 Manual
ITEM
No.
DESCRIPTIONPART No.
1 06 0 055104 Top Cover
2 58 0435 018 Cooling Fan
3 13 6690 000 Impellor for Agitator
4 85 6005 818 Cover - Hole
5 80 0800 710 Peardrop Knob Threaded
6a 14 5225 201 Faucet
6b 58 0483 002 Dispense Tap BT50
7 58 1185 111 Cup Rest
8 58 1185 102 Drip Tray
9a 58 0900 951 Comp. Set SC10GX HST
9b 14 3627 115 Comp. Set FF10GX HST (115v)
10 14 3297 000 Condenser
11 58 0431 015 Fan Blade 8"x30° CW
12a 58 0410 188 Fan Motor 11W 230V M/TEK CCWSE
12b 58 0410 191 Fan Mtr. 10W 115V60HZ M/TEK CCWSE
13 58 1174 007 Thermostat Superspot
14a 99 1180 126 Agit Motor Assy.
3
/
4
" Stack Gain
14b 06 0 050114 Agit. Mtr. Assy.
3
/
4
" Stack 115v
Not 99 0900 002 Compressor Fixing Assy
Shown
12. C20 (06 1 050101/102/201) SPARE PARTS LIST
