Cornelius C10 - C20 Spare Parts List (Model 06 1 050103)

13
®
C10/C20 Manual
ITEM
No.
DESCRIPTIONPART No.
1 06 0 055104 Top Cover
2 58 0435 018 Cooling Fan
3 03 1BF0 33A No. 62 Propellor 66mm DIA (103)
4 85 6005 818 Cover - Hole
5 80 0800 710 Peardrop Knob Threaded
6 84 4206 111 Dalex 200 NFCF 3/8 DH PN C10
7 58 1185 111 Cup Rest
8 58 1185 102 Drip Tray
9 58 0900 951 Comp. Set SC10GX HST
10 14 3297 000 Condenser
11 58 0431 015 Fan Blade 8"x30° CW
12 58 0410 188 Fan Motor 11W 230V M/TEK CCWSE
13 58 1174 007 Thermostat Superspot
14 58 1180 135 Agit. Motor Assy.
3
/
4
" Stack Gain (103)
Not 99 0900 002 Compressor Fixing Assy
Shown
14. C20 (06 1 050103) SPARE PARTS LIST
