MONTHLY MAINTENANCE
Check the water level in the ice bank and replenish it when it is low, as described in Table 4.
Table 4
1
Access the ice bank for water filling.
A. Lift grill upwards and pull bottom towards the front to
disengage the locking tabs in the bottom frame assem‐
bly
B. Unfasten cover (remove 2 screws at top of cover).
C. Slide filter to the left
2
Open the ice‐bank water‐refill cover.
A. Remove the thumbscrew securing the ice‐bank refill
cover.
B. Lift off the cover and set it aside.
Cover
Thumbscrew
Water Fill Tube
To Next Page
