17.
Slide the flavour hose sheathing on
injector module.
Sheathing Hose
Figure 25.
18.
Connect the power cord to the
appliance inlet.
Figure 26.
19.
Connect the power cord of the viper.
20.
For Brix Setting and Brix adjustment refer Viper manual.
Table 5: Installation of Valve
Appliance Inlet
