Appendix A: System Specifications
MA1000 Installation and Configuration Guide 30
Optical Specifications
Optical Output Power <3.0mW
Max. Optical Budget
2 dB for fiber + 1 dB for Connectors (assumed) = 3 dB total. 300 m Multi-
mode
Optical Loss per Mated-
pair Connectors
0.5dB (max)
Optical Connector SC APC
Fiber Type
Single-mode: 9/125um
Multi-mode: 50/125 um or 62.5/125um (Minimum qualifications with
ANSI/TIA/EIA-568-B series, EN50173-1 or ISO/IEC 11801)
Wavelength 1310±10nm
Maximum Distance
Between Base Unit and
Remote Cabinet
2km
Multimode Fiber Qualifications
50/125 or 62.5/125um complying with ANSI/TIA/EIA-569-B series, EN50173-1 or ISO/IEC 11801, may be used
up to 300 meters in length assuming the following qualifications:
• Both the Base Unit and Remote hub must be multimode capable
• All fiber in a given length of fiber must be of the same core diameter
• All Bulkhead adapters must be single mode SC/APC (Green) adapters
• All terminations, cross connections or patches must be direct fusion splice or one of the Corning
MOBILEACCESS cords listed below
900 micro patchcord for splicing, 2 meters, 2xSC/APC
62.5/125/900 Diamond p/n ENC/1045341 FiberNext p/n OEM-629002-MAN
50/125/900 Diamond p/n ENC/1045340 FiberNext p/n OEM-509002-MAN
Zipcord patchcord, 4xSC/APC, 50/125/900/2000/4500 micron
1 meter Diamond p/n ENC/1045342 FiberNext p/n OEM-50ZIP1-MAN
3 meter Diamond p/n ENC/1045343 FiberNext p/n OEM-50ZIP3-MAN
Zipcord patchcord, 4xSC/APC, 62.5/125/900/2000/4500 micron
1 meter Diamond p/n ENC/1045344 FiberNext p/n OEM-62ZIP1-MAN
3 meter Diamond p/n ENC/1045345 FiberNext p/n OEM-62ZIP3-MAN
Environmental
Operating 0°C to +50°C (32°F to 122°F)
Storage -20°C to 85°C (-4°F to 185°F)
