ORDINARY MAINTENANCE - 39
COROB™ D600 - D700 - D800 EXTRA
7.6 Cleaning and moistening the humidier cap sponge
In case of sponge replacement, use only those supplied with the machine.
8 mm To remove the Autocap screw(s)
DANGER
IF THE MACHINE IS EQUIPPED WITH PUNCHING DEVICE, YOU MUST WEAR CUT-PROOF GLOVES.
1. Open the Autocap...
I using the command in the management software. II
bringing the machine to the off-line 2 condition,
by means of the off-line button.
2. Disconnect power supply (chapter 5.8).
3. If present, open the inspection door in the dispensing area.
4. Loosen the screw A and the second screw B (if present), and remove the sponge support C by turning it
counter-clockwise.
A
C
BB
Figure 24
