24 - USING THE DISPENSER
COROB™ D800 HD
6.3.1 Loading the can - Roll Conveyor
Place the can on the roll conveyor and slide it under the dispensing nozzles.1.
For 1 Gallon tinting, lift up on the built-in shelf just past horizontal and then lower until it locks into place 2.
and position the can under the dispensing nozzles.
1 2
MAX
MIN
MAX
MIN
Loading the can - Pull Out Shelf6.3.2
Pull out the shelf and place the can in the centering ring of the appropriate diameter.1.
