corob D800 HD - Dimensions

36 - TECHNICAL SPECIFICATIONS
COROB™ D800 HD
Dimensions8.2
MAX
MIN
B
A
B2
B1
C
A - Width
61.7” (1566 mm)
B - Depth
38.3” (972,5 mm)
B1 - Depth (with roll conveyor)
47.2” (1200 mm)
B2 - Depth (with automatic shelf)
45.9” (1165 mm)
C - Height
47.1” (1197 mm)
Machine 948 lb (430 kg)
Packed machine 1146 lb (520 kg)
* Data are indicative, depend on machine conguration, and refer to the machine with empty canisters.
