4-72
Section 4
Observerʼs Seat
Lift up on the bottom of the observer’s seat cushion to access
storage under the bow area. You can leave the seat in the “UP”
position to help dry the carpet.
Storage Hatch
To open the storage hatch, lift the latch and turn counterclockwise.
The gas shock will help raise the hatch. To close and latch the
hatch, pull down on the hatch and allow the hatch to close firmly.
Make sure there are no hands, fingers or any other obstructions in
the way of the hatch when you close it. To close the latch, turn the
latch clockwise and fold the red dot down.
The storage hatch latch features a lock. Use the key to lock and
unlock the latch. The key only requires about a 10° turn to lock and
unlock.
