CORRECT CRAFT 210 - Ignition and Switch Panel

3-8
Section 3
Ignition and Switch Panel
1. Keyless Ignition Key Pad
2. Belly Ballast (if equipped)
3. Port Ballast (if equipped)
4. Starboard Ballast (if equipped)
5. Underwater Lights
6. Heater Fan
7. Courtesy Lights/Docking lights
8. Navigation Lights/Anchor Light
9. Bilge Pumps
10. Engine Compartment/Bilge Area Blower
11. Horn
12. System Indicator Light
13. Ignition Indicator Light
NOTICE
If your boat is not equipped with the features on the Ignition and
Switch Panel Switch buttons, the button will not have a function.
A full description of the key pad keys and switch buttons and their
functions is discussed in Section 4, Smart Pod - Limited or
Team, Control Switches and Ballast Tank Control Switches.
START
CORC083
1
2
3
4
5
6
8
9
10
7
11
12
13
