4-76
Section 4
Engine Cooling Water Intake Valve
Your Nautique is equipped with a valve (seacock) on the engine
cooling water intake. The handle has a slide mechanism to prevent
the valve from being shut off inadvertently. The valve is used to shut
off the water supply in the event a hose failure or water leakage
occurs. The valve is open when the blue handle is in-line with the
valve body and the valve is closed when the handle is perpendicular
to the valve body. Leave the valve open at all times unless an
emergency condition requires you to close the valve to stop a leak
or the possibility of a leak.
The valve is located fore of the engine compartment. If your boat is
equipped with a ballast system, the engine cooling valve (A) will be
the larger valve with a red locking handle. The valve can be
accessed through openings under the aft cockpit seat.
210
