Description
1. Bow Navigation Light
2. Bow Lifting Ring
3. 12V Port
4. Bilge Pump Outlet
5. Belly Ballast Tank Vent
6. Dash Pod and Console
7. Hydro-Gate™ Control and SportShift
8. Removable Cooler
9. Engine Cooling Water Intake Shutoff Valve
10. Engine Cooling Water Intake Strainer
11. Battery
12. Fuel Tank Fill
13. Starboard Ballast Tank Vent
14. Battery Selector Switch
15. Trunk Storage Access
16. Anchor Light Receptacle
(not included with Flight Control Tower
®
option)
17. Aft Built-In Cooler
18. Transom Lifting Eyes
19. Rudder Shaft Remote Lube Fitting
20. Pop-Up Water Sports Tow Point
21. Boarding Platform
22. Port Ballast Tank Vent
23. Fuel Tank Vent
24. Starboard and Port Ballast Tank Water Intake/Drain Valves/
Belly Tank Water Intake/Drain Valve
25. Love Seat/Storage Access
26. Glove Box/Stereo/Auxiliary Input/12V Port
The 230 primary battery is under the aft port seat and the secondary
battery is under the aft starboard seat. The battery selector switch is in
the port aft storage area.
