Jumpers, Connectors and Headers Quick Reference Table
Jumpers Name Description
JBAT CMOS Reset 3x1 header, pitch 2.54mm
JP1 COM1 RI Function Selection 3x2 header, pitch 2.54mm
JP2 Mini-PCI-E Standby Voltage Selection 3x1 header, pitch 2.54mm
JP4 COM3 RI Function Selection 3x1 header, pitch 2.54mm
JP5 COM5 RI Function Selection 3x1 header, pitch 2.54mm
JP8 COM4 RI Function Selection 3x2 header, pitch 2.54mm
JP9 COM6 RI Function Selection 3x2 header, pitch 2.54mm
JP12 COM3 RS232/422/485 Selection 3x2 header, pitch 2.54mm
JP13 RESERVED 2x1 header, pitch 2.54mm
JP15 Internal POST display (left) 2x1 header, pitch 2.54mm
JP16 Internal POST display (right) 2x1 header, pitch 2.54mm
Header Name Description
COM3/COM4/COM5/COM6 Serial Ports 5x2 header, pitch 2.54mm
CASE_OPEN Chassis Intrusion header 2x1 header, pitch 2.54mm
CPUFAN Processor Fan header (PWM) 4x1 header, pitch 2.54mm
FP_AUDIO Front Panel AUDIO header 5x2 header, pitch 2.54mm
GPIO_CON GPIO header 5x2 header, pitch 2.54mm
HDMI_SPDIF SPDIF Out header 2x1 header, pitch 2.54mm
FPANEL Front Panel header 5x2 header, pitch 2.54mm
KBMS PS/2 Keyboard/Mouse header 6x1 header, pitch 2.00mm
NIC1_LED LAN LED header 2x1 header, pitch 2.54mm
NIC2_LED LAN LED header 2x1 header, pitch 2.54mm
PARALLEL Parallel Port header 13x2 header, pitch 2.54mm
PWR_LED Power LED 3x1 header, pitch 2.54mm
SM_BUS SMBUS header 4x1 header, pitch 2.54mm
SPEAK Speaker header 4x1 header, pitch 2.54mm
SYSFAN1 System Fan header 4x1 header, pitch 2.54mm
SYSFAN2 System Fan header 4x1 header, pitch 2.54mm
TPM Trusted Platform Module header 10x2 header, pitch 2.54mm
TX-RXCOM RS-422/485 header 2x2 header, pitch 2.54mm
USB1 USB3.0 header 10x2 header, pitch 2.00mm
USB2/USB3 USB2.0 header 5x2 header, pitch 2.54mm
