15
Connector Name Description Type
AUDIO1 Line-out/Line-in/Microphone 3 phone Jack
ATXPWR ATX Power Connector 12x2 connector
ATX12V ATX 12V Connector 2x2 connector
COM1 Serial Port connector DB-9
COM2 Serial Port connector DB-9
CPU Processor Socket 1155 pin LGA socket
DIMM DDR3 DIMM memory sockets 240 pin
DVI DVI-D
DP Displayport
MINIPCIE Half size miniPCIe
MSATA MSATA
NIC1 UL1 Stacked RJ-45
NIC2 UL2 Stacked RJ-45
PCI1 PCI 32bit
PCI2 PCI 32bit
PCI3 PCI 32bit
PCI4 PCI 32bit
PE1 PCI Express x16
PE2 PCI Express x4
PE3 PCI Express x1
SATA1 and 2 Serial ATAIII Connector Shrouded and powered
SATA3, 4, 5 and 6 Serial ATAII Connector Shrouded and powered
USB3.0 USB4 Dual USB-A
USB2.0 UL1 Dual USB-A
USB2.0 UL2 Dual USB-A
VGA Analog Video connector DB-15
