CORVUS TERRAIN T21 - Heating System

We reserve the right to modify the product and the design.15
USER
MANUAL
HEATING SYSTEM
CLIMATE DIFFUSERS
Use the selector switch (1) to change
the air distribution at the diusers of the
heating system. By turning the selector
switch clockwise, an electrically controlled
valve will open to allow more air flow to the
diusers (B) at the front window.
The heating system improves visibility
and helps to prevent the front window
from fogging up. It is therefore
important that you are familiar with
the correct operation of the heating
system.
The heating selector switches are located
in the lower centre of the instrument panel.
Their functions are as follows:
- Selector (1) of the output air flow in the
diusers of the front windscreen (B).
- Selector (2) of the output air flow.
- Selector (3) of the output air flow
temperature.
The temperature selector (3) does not allow you to obtain a temperature lower than the ambient
temperature. To obtain more calorific power, the engine must be at operating temperature.
If the heating unit does not work properly, please contact Corvus service.
The heater can only work when the engine is running.
B
B
A
AA
B
B
2
1
3
