USER
MANUAL
Rear lamps (TURN SIGNALS, brake and sidelights)
The bulbs and the pilot light cover may be very hot.
Replacement procedure:
1. To access the rear lamps, you will have to remove the light cover that is
anchored with the two screws indicated in the image (1).
2. You will then be able to see the 2 lamps:
- Indicator (2)
- Brake and sidelight (3)
Do not drive the vehicle without brake, turn signal or sidelights as
these are important safety features.
NUMBER PLATE HOLDER BULB
To access the number plate holder bulbs, it is necessary to follow these steps:
1. Remove the screws shown (4).
2. Then remove the outer plastic of the lamp (5).
3. Carefully remove the bulb (6).
TECHNICAL INFORMATION
Indicator lamp: 12V 21W // Ref. 09180040001
Brake and sidelight lamp: 12V 21W/5W // Ref. 09180040002
Number plate light bulb: Ref. 08001660000
1
2 3
4
5
5
6
6
