* Equipment available depending on version.
We reserve the right to modify the product and the design.
9
USER
MANUAL
Driving seat
1. Instrument panel.
2. Emergency signal button.
3. Adjustable and sealable central air vents*.
4. 12V accessories socket.
5. Top air diuser for windshield demisting*.
6. Lights control, steering indicators and horn.
7. Key start-up.
8. Instrument panel button panel.
9. Gear lever.
10. Co-pilot grip handle.
11. Steering wheel.
12. Air temperature selection control*.
13. Blower intensity control*.
14. Cold air selection control*.
15. Brake pedal.
16. Accelerator pedal.
17. A/C selection button*.
18. Temperature selection control*.
19. Air intensity selection control*.
20. Fuse box
1
2
11
5
4
7
10
8
9
6
16
17
15
3
3
1918
20
3
3
12
13
14
