* Equipment available depending on version.
We reserve the right to modify the product and the design.
57
USER
MANUAL
Luggage compartment hood
DISASSEMBLY:
To gain access to the dierential and the components located under the
hood, it will be necessary to remove the luggage compartment if there is
one.
Previously, you need to remove the front hood.
1. Loosen the 5 screws (1) that hold the luggage compartment hood in
place.
2. Remove the luggage compartment hood.
TECHNICAL INFORMATION
Lock screws tightening torque: 12 Nm.
NEVER drive the vehicle with the luggage compartment hood
removed.
1
