MAINTENANCE INTERVAL RESET
Resetting the service will establish the next revision at 200hours, 2,500km or 1 year without considering the values at the time the reset is performed.
To reset the service interval, press ''MODE'' for 10 seconds (the service icon will flash), then press "TRIP" for 5 seconds. We have 10 seconds within which
to press the TRIP button once the service icon flashes, before it times out.
You cannot be moving at any speed when performing the reset.
24 h clock
The clock is displayed in the 24H format (HH:MM + a Clock symbol). To reset the clock, follow the procedure below:
• Press the MODE button for more than 2 seconds (until the two hour digits flash).
• Repeatedly press the TRIP button to increase the digits of the hours.
• Keep pressing the TRIP button to increase the hours.
• Press the MODE button to accept the hours and change the field to the minute units.
• Repeatedly press the TRIP button to increase the minutes.
• Keep pressing TRIP to increase the minutes.
• Press the MODE button to accept the minutes and exit the clock setting function.
• If you do nothing for more than 10 seconds, and if you have not pressed any button, the clock setting function is exited automatically.
• If you have changed the hour or minutes, but you do not save them, the time-out will be 20 seconds.
• You can only change the time if the vehicle is completely stopped, without any speed pulses being received.
Gear
The gear will be indicated on the screen by an alphanumeric digit that can display:
- N to indicate that you are in NEUTRAL.
- R to indicate that you are in REVERSE GEAR.
- L to indicate that you are in SHORT GEAR.
- H to indicate that you are in LONG GEAR.
Revolution counter
The instrument displays the engine revolutions via a bar indicator.
It has a total of 10bars that will serve to indicate the range of 0 to 5000rpm (one bar is equivalent to 500rpm).
multifunction panel
