We reserve the right to modify the product and the design.59
USER
MANUAL
LIGHTING
ADJUSTING THE HEIGHT
1. Position the vehicle 10 meters from a wall and use the parking brake to immobilize it.
2. Use the screws to adjust the headlamps (1).
3. The light beam must be 30 cm below the horizontal line projected onto the wall from the centre of the headlamp.
The bulbs and headlamps may be very hot.
30 cm below the cen-
tral line of the head-
lamp
Central line of the headlamp
10 metres between the vehicle and the wall
