* Equipment available depending on version.
We reserve the right to modify the product and the design.
68
USER
MANUAL
windshield wiper
WINDSHIELD WIPER BLADE *
To remove the windshield wiper blade:
1 - Separate the windshield wiper arm.
The arm and the blade must form an angle of 90º.
2 - Press the central clip.
3 - Remove the blade downwards.
To assemble the blade:
1 - Place the windshield wiper arm between the blade.
2 - Place the tip of the arm onto the central clip.
3 - Twist the blade and return the arm to its initial position.
WINDSHIELD CLEANER FLUID *
The windscreen wiper fluid reservoir is located under the front hood.
1 - Put the vehicle in a horizontal position.
2 - Remove the four screws from the cover.
3 - Remove the cap.
4 - Fill the tank with fluid up to the top.
5 - Screw the cap back on.
6 - Check it works properly.
