23
INSTALL THE MICROWAVE OVEN – RECIRCULATING
1. Make sure the microwave oven door is closed.
2. Using 2 or more people, lift and tilt forward the microwave oven and
hang it on support tabs at the bottom of the wall mounting plate.
NOTE: To avoid damage to the microwave oven, do not grip or use the
door or door handle while the microwave oven is being handled.
3. With front of microwave oven still tilted, thread power supply cord
through the power supply cord hole in the bottom of the upper cabinet.
4. For recessed cabinets, insert and place the filler blocks on the microwave
oven below the cabinet screw holes.
NOTE: If filler blocks are not used, case damage may occur from
overtightening screws.
Cabinet Front
Cabinet Bottom
Filler Block
Self-Aligning Screw
Microwave Oven Top
Equivalent to
Depth of
Cabinet Recess
To Next Page
