33
3. Seal all joints in the duct system using duct tape.
FOR REAR VENTING (DUCTED, WALL/HORIZONTAL
VENTING) ONLY
ATTACH WALL MOUNTING PLATE – REAR VENTING
NOTE: If top cabinets are deeper than 13.8" (35 cm), the unit must be spaced
out from the wall using adequate materials supporting 150 lbs to allow top
vent airflow in the front. These materials are not provided.
IMPORTANT: Read the instructions on the Rear Wall Mounting Template.
Ductwork
