7
LOCATION REQUIREMENTS
IMPORTANT: Check the opening where the microwave oven will be installed.
The location must provide:
• The unit must be mounted to both a top cabinet and a wall. It cannot be
installed in cabinet arrangements such as an island or a peninsula.
• Minimum installation dimensions. See the "Installation Dimensions"
illustration.
• Minimum one 2" x 4" (50.8 x 101.6 mm) wood wall stud and minimum
3
/
8
"
(10 mm) thickness drywall or plaster/lath within cabinet opening.
• Support for weight of 150 lbs (68 kg) which includes microwave oven and
items placed inside the microwave oven and upper cabinet.
• Grounded electrical outlet inside upper cabinet. See the "Electrical
Requirements" section.
NOTES:
• If installing the microwave oven near a left sidewall, make sure there is at
least 6" (15.2 cm) of clearance between the wall and the microwave oven
so that the door can open fully.
• Some cabinet and building materials are not designed to withstand the
heat produced by the microwave oven for cooking. Check with your
builder or cabinet supplier to make sure that the materials used will not
discolor, delaminate, or sustain other damages.
SPECIAL REQUIREMENTS
For Wall Venting Installation Only:
• Cutout must be free of any obstructions so that the vent fits properly and
the damper blade opens freely and fully.
For Roof Venting Installation Only:
• If you are using a rectangular-to-round transition piece, the 3" (7.6 cm)
clearance needs to exist above the microwave oven so that the damper
blade can open freely and fully.
