1
#2 x 2″ Robertson bit.
33
5/16″ nylon washer used to
connect the U-frames
17
5/16″ painted washer.
2
1/4″ nylon washers used to
fasten the bottom of the
sleeves with M6 x 20 mm
screw.
2
M6 clip-on barrel nut used to
secure the sleeve at the bottom
of each post.
