COVANA Evolution Series - TECHNICAL SPECIFICATIONS; Side Elevation Dimensions and Clearance

42 TECHNICAL SPECIFICATIONS INSTALLATION MANUAL
TECHNICAL SPECIFICATIONS
Side elevation dimensions
Figure 83
The maximum raised height depends on
the height of the hot tub. Add the hot tub
height to distance the Covana cover
travels to determine the maximum height.
Example :
Hot tub height + Covana travel
(52 in. or 132 cm) = Total height
The maximum distance the
Covana cover travels is 52 in.
(132 cm).
The hot tub must fit within these height
specifications:
Min: 34 in. (86 cm)
Max: 48 in. (122 cm)
