COVANA Evolution Series - Grounding and Power Supply Connection

INSTALLATION MANUAL ELECTRICAL HOOK-UP 41
Grounding lug
(green) ⏚
Electrical input
Bonding lugs
(copper)
Grounding and power supply connection
1) Remove the four screws on the bottom side of the Covana operator and remove the cover. (Figure 86)
2) Refer to the complete wiring diagrams for the European model and North American model in the appendix
Figure 82
