Output Characteristics
9-16 Force FX Electrosurgical Generator C User’s Guide
Monopolar Coag
Desiccate 240 kHz sinusoid repeated at 39 kHz; 8% duty cycle
Fulgurate 470 kHz damped sinusoidal bursts with a repetition
frequency of 30 kHz into 500 ohms
LCF Fulgurate 470 kHz damped sinusoidal bursts with a repetition
frequency of 57 kHz into 500 ohms
Spray 470 kHz damped sinusoidal bursts with a randomized
repetition centered at 28 kHz.
Frequencies include 21 kHz < f < 35 kHz. Output is
further modulated by a random 250 Hz envelope with
a variable duty cycle.
