Bipolar Instrument Receptacle
2-4 Force FX Electrosurgical Generator C User’s Guide
Bipolar Instrument Receptacle
You can connect either a footswitching or handswitching bipolar instrument to the
Bipolar receptacle.
Connect a footswitching instrument with a two-pin connector.
or
Connect a handswitching instrument with a three-pin connector.
Caution
Accessories must be connected to the proper receptacle type. In particular, bipolar accessories
must be connected to the Bipolar receptacle only. Improper connection may result in inadvertent
generator activation or a REM Contact Quality Monitor alarm
