No. Part name Explanation Reference picture
2 Feed-NOS
Valve
Assy
1) Separate the 2 fittings and
remove the screw from the
Feed-NOS valve assy.
: 4x12 T
AP -
5) Remove the Feed-NOS Valve
Assy in the right-hand direction.
3 3-way valve
assy
1) Remove the 2 screws from the
3-way valve and cut 2 cable ties
and remove 2 band ties from the
silicon hoses.
: 2-4x12
T
AP -
2) Separate the 2 silicon hoses
connected to each tank.
To Next Page
