1. Initial power supply (operation wating mode)
Classification
Item Type Function
INPUT
Cold/Hot water
selection switch
TACT
S/W Waiting
Extracton switch
Electrostatic capacity
switch
Waiting
Hot water lock switch
TACT
S/W Waiting
Hot water temperature
sensor
Thermistor Detects the hot water tank temperature.
Cold water
temperature sensor
Thermistor Detects the cold water tank temperature.
Water level sensor
REED LEVEL sensor
Detects low/full water level and water
overflow.
Light sensor CDS Senses illumination.
OUTPUT
FND indication part
Hot water LED
When the power is turned on, it flashes
twice and then goes off.
EEPROM is checked and then the set value
is displayed.
Cold water
temperature LED
Status LED
Cold/hot/room
temperature water
selection LED
When the power is turne on, it flashes twice
and then the cold water LED turns on.
Extraction LED
When the power is turne on, it flashes twice
and then the cold water LED turns on.
Hot water lock LED
When the power is turned on, it flashes
twice and then goes off.
EEPROM is checked and then the set value
is displayed.
Water heater Heater
Default: OFF
EEPROM is checked and then the set value
operates.
Cold water compressor
COMP
.
Default: OFF
EEPROM is checked and then the set value
operates.
When the power is turned on, the
compressor stays off until the low water
level becomes SHORT.
Cooling FAN BOX FAN
Default: OFF
Operates according to the cooling
compressor function.
Operation bell Bell
When the power is turned on a bell rings
(ding).
Extraction valve 3-W
A
Y V/V OFF
Feed water valve FEED V/V
Reading the water level sensor signal, it
is turned on when detecting the low water
level below SHORT
for 4 seccond and
turned off when detecting the full water level
for 1 minute.
NOS valve NOS V/V
It is turned on when detecting overflow
for 20 seconds and turned off when the
overflow is cancelled (normal operation).
1) Compensation for power cut-off:
When the power is turned off and then on again during normal operation, the previous setting is
maintained. Whe the power is connected for the first time, basically all functions are set OFF.
After checking the stored values on the EEPROM, input and output are set.
