CPAP Freedom - Devilbiss Intellipap Series; Single Battery Connection

8
Other Charging Options
27
AUTO CHARGE DC CABLE
{ITEM #: BPS DC.CABLE}
When AC power is not available you can still keep the Freedom
TM
CPAP
Battery charged up and ready to go. Optional accessories are available
for charging the battery in a vehicle or by using the power of the sun. For
more detailed information on these charging accessories visit our website
at www.batterypowersolutions.net or call us at 1-877-445-5228.
AUTO CHARGE DC CABLE
The auto charge DC cable lets you connect the battery directly to the
cigarette lighter/power socket of a vehicle. The vehicle must be running
during the charging process in order to obtain the proper voltage to
successfully charge the battery. We do not recommend using any other
brand of “universal” auto charge cable as it may damage the internal
circuitry of the Freedom™ CPAP Battery.
150W SINE WAVE POWER INVERTER
The 150W sine wave power inverter lets you charge the battery via the
cigarette lighter/power socket of a vehicle by plugging the battery AC
power supply into the inverter and then plugging the inverter into the
vehicle. The vehicle does not need to be running during the charging
process to obtain the proper voltage to successfully charge the battery.
SUNPOWER 40W SOLAR PANEL
The SunPower 40W solar panel lets you use the power of the sun to charge
the battery. The solar panel also comes with a DC input cord so you can
charge other small electronic devices that operate from 18V or less by
using the device’s DC power cord.
150W SINE WAVE
POWER INVERTER
{ITEM #: BPS INVERTER}
SUNPOWER 40W
SOLAR PANEL
{ITEM #: BPS SP40}
Power Backup Usage - Single Battery
When using a single Freedom
TM
battery in the power backup scenario you
simply plug the battery into a wall outlet as if you were charging it and
then connect your PAP device to the battery.
The AC power supply of the Freedom
TM
battery will be plugged into the DC
IN jack of the battery and then into a wall outlet. Your PAP device will then
be connected to the battery via the DC OUT jack of the battery using the
appropriate method for your specific model device as noted in this manual.
RESPIRONICS DREAMSTATION SERIES
 Plug the AC power supply of the battery into the DC IN jack of the
battery and then plug the AC power supply of the battery into a wall
outlet (see page 6).
 Plug the 12V power adapter into the DC OUT jack of the battery and
then plug the 12V power adapter into the DC input port of the
DreamStation series PAP device (see page 9).
RESPIRONICS SYSTEM ONE/M & DEVILBISS INTELLIPAP SERIES
 Plug the AC power supply of the battery into the DC IN jack of the
battery and then plug the AC power supply of the battery into a wall
outlet (see page 6).
 Plug the DC power pigtail cord into the DC OUT jack of the battery.
 Insert the appropriate connector tip into the DC power pigtail cord.
 System One 60 Series: Tip with black top labeled “W”
 System One 50 & M Series: Tip with yellow top labeled “N”
 Plug the DC power pigtail cord with appropriate connector tip attached
into the DC input port of the PAP device (see page 11).
*NOTE: DeVilbiss IntelliPAP 2 series devices will connect to the Freedom
TM
CPAP Battery via the 150W Sine Wave Power Inverter (see page 28).
