103
Environment
Enclosure Protection Degree
NEMA Type 4X
Cooling Method
Variable speed cooling fans
Operation Temperature
Range
-22°F to +140°F/- 30°C to +60°C (derating from
+113°F/+45°C)
Storage Temperature Range
-40F to +158°F/-40°C +70°C maximum
Operating Humidity
0-95%, non-condensing
Operating Altitude
8202ft / 2500m
Display and Communication
User Interface and Display
LED Indicators, APP
Inverter Monitoring
Modbus RS485 / PLC Option
Site Level Monitoring
CPS Flex Gateway (1 per 32 inverters)
Modbus Data Mapping
SunSpec/CPS
Remote Diagnostics / FW
Upgrade Functions
Standard with CPS Flex Gateway
Mechanical Data
Dimensions (WxHxD) (mm)
45.28x24.25x9.84in (1150x616x250mm) with Standard
Wire-box
39.37x24.25x9.84in (1000x616x250mm) with Centralized
Wire-box
Weight (kg)
Inverter: 121lbs / 55kg; Wire-box: 55lbs / 25kg (Standard
Wire-box); 33lbs / 15kg (Centralized Wire-box)
Mounting/Installation Angle
15- 90 degrees from horizontal
Safety
Safety and EMC Standard
CSA-C22.2 NO.107.1-16, UL Std. No. 1741,
CSA TIL M-07, FCC CFR 47 part15, ANSI C63.4-2014
Grid Standard and SRD
IEEE 1547a-2014, IEEE1547-2003(R2008), IEEE1547.1-
2005(R2011), IEEE1547.1a-2015, CA Rule 21 and UL1741
Supplement A, ISO-NE
1) "Max. AC Apparent Power" rating at an operating voltage and temperature range of -30°C to +40°C (-
22°F to +104°F) can output.
2) The "Output Voltage Range" and "Output Frequency Range" may differ according to the specific grid
standard.
3) Wye can support the TT/TN-C/TN-S/TN-C-S, Delta cannot support Grounding system.
4) GFCI in AC Switchgear required for Floating AC systems.
