Chapter 8 Technical Data
(for Reference Only – Refer to Datasheet on website for latest information)
SCH100KTL-
DO/US-600
SCH125KTL-
DO/US-600
SCH100KTL-
DO/US-600
DC Input – UNGROUNDED ARRAY
Max. PV Power
187.5kWdc
Max. DC Input Voltage
1500Vdc
Operating DC Input Voltage Range
860-1450Vdc
750-1450Vdc
MPPT Voltage Range
870-1300Vdc
760-1300Vdc
Start-up DC Input Voltage
900V
Number of DC Inputs
20 PV source circuits, pos. & neg. fused (Standard Wire-box);
1 PV output circuit, 1-2 terminations per pole, non-fused
(Centralized Wire-box)
Max. PV Input Current (Isc x 1.25)
275A
DC Disconnection Type
Load rated DC Switch
AC Output – Grounded WYE/Floating WYE/FLOATING DELTA (Note 4)
Rated AC Output Power
100kW
125kW
100kW
Max. AC Output Power
100kVA
(111KVA
@PF>0.9)
125kVA/
(132KVA @
PF>0.95)
100kVA
(105.3KVA
@PF>0.95)
Rated Output Voltage
600Vac
480Vac
Output Voltage Range (2)
528-660Vac
423-528Vac
Grid Connection Type (3)
3Φ / PE / N (Neutral optional)
Max AC Output Current
96.3/106.8A @
600V
120.3/127.0A @
600V
120.3/126.7A @
600V
Rated Output Frequency
60Hz
Output Frequency Range
57-63Hz
Power Factor
>0.99 (±0.8 adjustable)
Current THD
<3%
AC Disconnection Type
Load-rated AC switch
System and Performance
Topology
Transformerless
Max. Efficiency
99.1%
98.9%
CEC Efficiency
98.5%
98.0%
Stand-by / Night consumption
<4W
