(2) Installation Method (see Figure 3-2):
Make sure that the mounting structure (bearing wall, rack, etc.) is suitable
to support the inverter weight. Follow the mounting guidelines below:
(a) If the location permits, install the inverter vertically.
(b) If the inverter cannot be mounted vertically, it may be tilted backward
to 15 degrees from horizontal.
(c) Do not mount the inverter leaning forward.
(d) Do not mount the inverter upside down.
(e) Do not mount the inverter horizontal installation.
NOTICE:
If the installation environment allows, avoiding direct sunlight from the
inverter, avoiding direct rain and snow, can extend the life of the inverter
(See Figure 3-3). Direct sun install does not impact warranty.
