67
Table 5-1a
Parameter
name
Description
Range
Grid code
IEEE-1547
Grid code
RULE-21
Grid code
ISO-NE
MOVING AVERAG PARAMETERS (Table 5.7 (25, 26))
VMaxMovAvg
Threshold max move
average Voltage
{100.00%,135.00%}
{110.00%}
{110.00%}
{110.00%}
VMaxMovAvgT
Trip time of max move
average Voltage
{0, 655}
{600}
{600}
{600}
VMinMovAvg
Threshold min move
average Voltage
{80.00%, 100.00%}
{88.00%}
{87.99%}
{88.00%}
VMinMovAvgT
Trip time of min move
average Voltage
{0, 655}
{600}
{600}
{600}
VOLTAGE UNBALANCE (Table 5.7 (32))
VUnbal
Threshold grid voltage
unbalance
(0.01%, 10%)
(10%)
(10%)
(10%)
