CPS SCH100KTL-DO-600 - Page 84

80
Table 5-6 The Enable/Disable Parameters (IEEE1547, Rule21 and ISO-NE)
REF
Parameter name
Description
Range
Grid code
IEEE-1547
Grid code
RULE-21
Grid code
ISO-NE
1
CtrlParaGroup
Control Loop
Parameters
{0,1,2,3,4}
{4}
{4}
{4}
2
CtrMode
ReactivePwMode
Reactive power
mode
Disable Dispatch
Remote Dispatch
Local Q
Locat PF
PF(P)
Q(U)
{Disable}
{Disable}
{Disable}
3
CtrMode
ActivePwMode
Active power mode
Disable Dispatch
Remote Dispatch
Local Control
{Disable}
{Disable}
{Disable}
4
MPPTScan
{Disable, Enable}
{Enable}
{Enable}
{Enable}
5
ArcEnable
AFCI
Not Available
{Disable, Enable}
{Disable}
{Disable}
{Disable}
6
ARCParaGroup
AFCI
Not Available
Reserved
Reserved
Reserved
Reserved
7
VpvStartUpSetEn
PV Voltage Min.
{Disable, Enable}
{Disable}
{Disable}
{Disable}
8
Island Protect
Anti-Island
{Disable, Enable}
{Enable}
{Enable}
{Enable}
9
LVRTModeSetting
Disable
Enable No Q
Enable w/ Q
{Disable}
{Enable w/Q}
{Disable}
10
HVRTModeSetting
Disable
Enable No Q
Enable w/ Q
{Disable}
{Enable No
Q}
{Disable}
11
NormSoftStopPEn
SoftStopEn
soft STOP ramp
function
{Disable, Enable}
{Enable}
{Enable}
{Enable}
12
PID Check Settings
No External PID
External PID Box
Reserved
No External
PID Box
No External
PID Box
No External
PID Box
13
GridVolMax1En
Grid Protection
{Disable, Enable}
{Enable}
{Enable}
{Enable}
14
GridVolMax2En
Grid Protection
{Disable, Enable}
{Enable}
{Enable}
{Enable}
15
GridVolMax3En
Grid Protection
{Disable, Enable}
{Disable}
{Disable}
{Disable}
16
GridVolMin1En
Grid Protection
{Disable, Enable}
{Enable}
{Enable}
{Enable}
17
GridVolMin2En
Grid Protection
{Disable, Enable}
{Enable}
{Enable}
{Enable}
18
GridVolMin3En
Grid Protection
{Disable, Enable}
{Disable}
{Disable}
{Disable}
19
GridFrqMax1En
Grid Protection
{Disable, Enable}
{Enable}
{Enable}
{Enable}
20
GridFrqMax2En
Grid Protection
{Disable, Enable}
{Enable}
{Enable}
{Enable}
21
GridFrqMax3En
Grid Protection
{Disable, Enable}
{Disable}
{Disable}
{Disable}
22
GridFrqMin1En
Grid Protection
{Disable, Enable}
{Enable}
{Enable}
{Enable}
23
GridFrqMin2En
Grid Protection
{Disable, Enable}
{Enable}
{Enable}
{Enable}
24
GridFrqMin3En
Grid Protection
{Disable, Enable}
{Disable}
{Disable}
{Disable}
