Craftex CX500 - Page 19

19
PART# DESC RIPTION
2
Base
3
Frame
4
Spindle
5
Helical Bevel Gear
6
PU Helical Bevel Gear
7
Right Oil Box
8
Left Oil Box
9
Connection Rod
10
Right Bracket
11
Left Bracket
12
Working Table
13
Bearing Fix Plate
14
Table
15
Auxiliary Left Scale Plate
16
Auxiliary Right Scale Plate
17
Dust Hood
18
Short Spacer
19
Long Spacer
20
Right Graduated Scale Base
22
Hand Knob 1/4"-20UNC X 3/8"
23
Motor
24
Switch Box
25
Switch (125/250V.20/12A 4POLES)
26
Indicator
27
Tilting Fix Bracket
28
Connection Block
29
Dust Hood
30
ARBOR
31
Guide Rod
32
1/4"-24 UNC * 1/4" soc set screw
33
Handle M6X1X15
34
Worm Gear
35
CAM
36
Copper Sleeve
37
Ball Bearing 6001zz
38
Worm Gear Shaft
39
Worm Gear Housing
40
Connection Piece
41
Side Cover
42
Front and Rear Cover (2PCS)
43
SPACER
44
Spindle (5/8")
45
6mm x 50mm Key
46
1/4" Spindle
47
2" Rubber Drum
48
1-1/2" Rubber Drum
52
SANDING SLEEVE(2",1-1/2",5/8",1/4")
57
Right Graduated Scale
58
Left Graduated Scale
59
Sanding Belt Pressure Plate
60
Sanding Platen
61
Upper Pressure Plate 2"
62
Upper Pressure Plate 1 1/2"
63
Upper Pressure Plate 2"
64
Flat Washer 5/16 X 2 X 18
65
5/16"-18UNC Hex Nut
66
2" Table Insert Elliptical
67
2" Table Insert Round
68
3/4" Table Insert Round
69
3/4" Table Insert Elliptical
71
Spring Pin 3 x 12mm
72
Open End Wrench 17mm
73
Open End Wrench
74
Spacing Collar
75
Strain Relief bushing 6N3-4
76
Power Cord
77
Graduated Scale
78
Positioning Rod
79
Spindle Washer
80
Foot Pad
81
SCREW 5/16 X 1/2 X 18UNC
82
Spring Washer 5/16"
83
5/16"-18 UNC Hex Nut
84
5mm x 15mm Key
85
6mm x 30mm Key
86
Hex Nut 3/8"-16UNC
87
Ball Bearing6804zz
88
C CirClip S-27
89
Ball Bearing6006zz
90
C CirClip S-27
91
Locking Nut M5
92
Washer 3/16"
93
Connection Shaft
94
C CirClip STW-12
95
C CirClip R-28
96
4mm x 15mm key
97
Rear Oil Cover
98
Pan Hd Screw 3/16"-24UNC x 1/4"
99
Spring washer 1/*4"
CX500 PARTS LIST
