8
ON/OFF POWER SWITCH
CX500 is equipped with a rocker-type
power switch which starts and stops the
motor and is loc ated on the junction box of
the motor. The switch features a removable
locking key to prevent unauthorized
operations. When the sander is not in use
for a long period of time, simply remove the
locking key and store it in a safe place.
To start the sander, insert the locking k ey
and shift the switch to the left.
Figure-3 On/Off Switch
HORIZONTAL/VERTICAL
SANDING
1. Loosen the screw securing the sander
frame to the motor bracket using a 6mm
hexagonal wrench.
Figure-4 Removing the screw
2. Remove the sanding belt table.
3. Move the belt sander to horizontal /
vertical position manually.
4. Tighten the screw securely after the belt
sander has been pos itioned horizontally
/ vertically.
Make sure to mount the stop fence when
performing flat surface sanding.
Figure-5 Installing stop fence
IMPORTANT
To prevent any type of accidental
injuries, make sure the power switch is in
the OFF position before connecting the
sander to the power source.
