SELECTION WILL NOT VEND
Loose
connections.
Defective
Plunger arm.
Defective
Harness.
Check Price, reset as needed.
Check Price, ensure credit is = to or
greater.
Selection will
not vend.
Vend Price set
incorrectly.
Insufficient
credit.
Check Gate & factory set up
recommendations for package.
Product & Gate
mismatch.
Move product away from Gate and use Test
Vend to check Gate operation. Check for bent
pins. Use small amount of WD-40 on pins and
recheck. Replace Gate as needed.
Clean, lubricate, check for flash,
replace Slide Assy.
Gate sticking.
Dirty / Worn
Tray Slide Assy.
Check Harness connections at VMC, Cup
Board, Port Board, X & Y Motor Boards, & X &
Y Motors.
Use Position Test to check Plunger arm,
replace Cup Assy. as necessary.
Cabinet
Control Board
Status Lights.
Check Cup Board, Port Board, X & Y Motor
Boards Green status lights are blinking. If only
one is On or Off, replace the Off Cabinet
Control Boards.
Replace Harness.
