5. Pull Rod Installation 拉杆安装
10
M5×12 Hexagon flat round
head screw x2
M5x12 内六角平圆头螺丝
12
M5x20 Hexagon flat round
head screws x2
M5x20 内六角平圆头螺丝
Adjust the proper length of assembled pull rod and install in the position shown in the figure
拉杆组装调节到合适的长度安装在图示位置
10
12
12
10
M5 Large Flat gasket
M5加大平垫
×2
13
13
05

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Creality CR-10 Smart Pro and is the answer not in the manual?

Creality CR-10 Smart Pro Specifications

General IconGeneral
Build Volume300 x 300 x 400 mm
Layer Resolution0.1-0.4 mm
Filament Diameter1.75 mm
Print Speedup to 180 mm/s
Touch Screen4.3-inch color touch screen
Bed Temperatureup to 100°C
Nozzle Temperatureup to 260°C
Printing TechnologyFDM (Fused Deposition Modeling)
Machine Dimensions578 x 522 x 648 mm
Resume Printing FunctionYes
Filament Runout SensorYes
Nozzle Diameter0.4 mm
ConnectivityWi-Fi, USB
Supported MaterialsPLA, ABS, PETG, TPU
Bed LevelingAutomatic Leveling
