Creality CR-10 User Manual

5
11) This machine is equipped with a security protection mechanism. Do not manually
move the nozzle and printing platform mechanism manually while booting up,
otherwise the device will automatically power off for safety.
12) Users should comply with the laws and regulations of the corresponding
countries and regions where the equipment is located (used), abide by
professional ethics, pay attention to safety obligations, and strictly prohibit the use
of our products or equipment for any illegal purposes. Creality will not be
responsible for any violators' legal liability under any circumstances.
Introduction
1
Z Gantry frame
8
Platform
14
Extruder (E)
stepper
2
Nozzle kit
9
Filament holder
15
X limit switch
3
TF slot and USB port
10
Control box
16
X stepper
4
Display screen
11
Nozzle assembly
connection
17
Z stepper
5
Control knob
18
Z limit switch
6
Voltage selection
12
Platform connection
19
Y limit switch
7
Base frame
13
Power cable
connection
20
Y stepper

Creality CR-10 Specifications

General

Build Volume	300 x 300 x 400 mm
Layer Resolution	0.1-0.4 mm
Nozzle Diameter	0.4 mm
Filament Diameter	1.75 mm
Connectivity	SD card, USB
Supported Materials	PLA, ABS, PETG, TPU
Printing Technology	FDM (Fused Deposition Modeling)
Display	LCD screen
Bed Leveling	Manual
Power Supply	110V / 220V
Frame Structure	Aluminum
Bed Temperature	Up to 100°C
Nozzle Temperature	Up to 250°C
