Creality CR-6 Max User Manual

Twist the coupling to raise the X axis
to the position as picture shown.
拧动联轴器使X轴上升到如图所示位置。
Install the Gantry Frame
安装龙门架
1
9
9
1
2
X-axis bottom profile
X轴底部型材
Two Z-axis profiles, installed on the
inner step of the X-axis bottom profile.
两根Z轴型材，靠X轴底部型材内侧台阶安
装。
9
M5x45 Sems Screw
M5x45组合螺丝
×4
x 1
Gantry Frame｜龙门架
2
x 1
Base Frame｜底座
1

Creality CR-6 Max Specifications

General

Build Volume	400 x 400 x 400 mm
Layer Resolution	0.1 - 0.4 mm
Nozzle Diameter	0.4 mm
Filament Diameter	1.75 mm
Connectivity	SD card, USB
Bed Leveling	Automatic
Frame Material	Aluminum
Nozzle Temperature	Up to 260°C
File Format	STL, OBJ, AMF
Feeder System	Bowden
Print Technology	FDM
Auto Leveling	Yes
Display	4.3-inch touchscreen
Supported Materials	PLA, ABS, PETG, TPU
Power Supply	24V
