EnderExtender.com – Ender Extender™ 5 Installation Guide
3
Loosen smooth rod mounting screws (4x)
from top and bottom supports.
4
Remove the M3 screws (4x) and nuts from
the lead screw brass nut
5
Remove the two smooth rods
