Page 13
EnderExtender.com – Ender Extender™ 5 Installation Guide
8
Loosen but do not remove the lead screw
set screw
Be careful! Do not strip the head.
Remove the lead screw from the coupler
Set the lead screw aside, it will not be
reused.
9
Remove Top front frame member
Remove the M5 (2x) screw at the top front
corners
Remove the M4 (2x) screw at the inside
bracket supporting the top front frame
member
