Creality HALOT R6 - Release Film (FEP) Replacement

6. Release Film (FEP) Replacement
07
Parameters
Size：200*140mm
Thickness：0.15mm
Light Transmittance: ＞95%
1
5 6
2
×
Recycle the resin in the resin vat back into the
original bottle , then clean up. (Note: Please make
sure there are no residue matter left inside the Vat)
Remove all the screws at the bottom of the resin vat, take
out the xing plate and the release lm. (Note: The xing
plate andthe vat bottom need to be cleaned)
3
Gently remove the protective lm of the release lm.
4
Align the release lm with the xing plate
Press into the bottom of the vat, and tighten the
screws diagonally across from each other one at
a time. (Note: Make sure there are no debris
between the xing plate and release lm)
Make sure the release lm is at and tight after installation.
(Note: If not at or loose, please check whether the screws
are locked or the release lm is abnormal)
Tips: ① The diagram is a reference for the lm change procedure, please refer to the physical product; if there are excess edges after installation
of the release lm, you will need to cut them o.
② It is recommended to replace the release lm when it has been used for more than 200 hours.
