Creality LD-002R User Manual

3) Press “up” or “down” to select files.
4) Select the file to be printed and press “print”.
5) Printing.
Clean the Resin Vat
* If there is residue in resin vat before printing, please clean resin vat first. The cleaning
time is generally set to 60 seconds and then shovel it off with a plastic blade.
Wiring Connection
RJ 485
Wi-FI module
5.5inch 2K
screen port
Z-axis
limit
Z-axis
motor
Mainboard
fan
Cooling
fan
UV
lighting
source
12V
power
supply
Restart
Touch screen part

Creality LD-002R Specifications

General

Technology	LCD-based SLA
Build Volume	119 x 65 x 160 mm
Z-axis Positioning Accuracy	0.00125 mm
Print Speed	20-30 mm/h
Connectivity	USB
Software	ChiTuBox
Power Supply	100-240V, 50/60Hz
Operating System	Windows, Mac OS
Resin Compatibility	405 nm UV resin
XY Resolution	0.047mm (2560 x 1440)
Light Source	UV LED
Supported File Formats	STL
Printer Dimensions	221 x 221 x 403 mm
