White Rabbit Switch - WRS
4 Login using Linux
4.1 Login via USB
To connect by USB you need a serial console, in instruction we used minicon.
## Connecting to the Management USB po r t
minicom −D /dev /ttyACM0 −b 115200
## Connecting to the FPGA UART
minicom −D /dev /ttyUSB0 −b 115200
## Connecting to the ARM UART
minicom −D /dev /ttyUSB1 −b 115200
Note: ttyUSB0 and ttyUSB1 usally correspond respectively to FGPA and ARM UART.
However this order can change dependably on how you plug the cable.
4.2 Login via SSH
The Ethernet management port automatically obtains its IP using the DHCP protocol.
If you don’t have any DHCP router/server in your network please refer to the non-DHCP
section. To obtain the IP of the WRS you can connect to your DHCP server interface and
retrieve the IP, or connect to ttyACM0 to retrieve the IP (ipconfig eth0). If the WRS IP is
for example 192.168.95.101 you might connect using:
ssh root@192 . 1 6 8 . 9 5 . 1 0 1
Then you need to press enter when requesting the password.
