White Rabbit Switch - WRS
5 Login using Windows
The process of login to the switch using Windows (XP,Vista,7,8,10) is pretty similar, we
used in instruction PuTTY - a free SSH client for Windows. First you need to download the
Putty Tool and install it.
5.1 Login via USB
1. You need to list and find out which serial port in Windows, corresponds to which
interface. A simple way to perform this is to plug only one USB cable at a time, and
go to DeviceM anager → P orts (COM & LPT) to check the name of the COMx port.
2. Then to connect through the USB you just need to open the Putty tool and configure
it as indicated in the figure below:
(a) mark Connection type: Serial
(b) type COM33 port and Speed: 115200
(c) click Open
Do not forget to replace the COM33 port name by corresponds to the USB management.
Creotech Instruments S.A. tel. +48 22 233 10 27
ul. Gen. L. Okulickiego 7/9 e-mail: support@creotech.pl
05-500 Piaseczno, Poland www.creotech.pl
Page 13 of 30
