12 • IV-SAM-VXP-1B and IV-SAM-VXS-1B Product Manual — Doc. 9324A
IV-SAM-VXP-1B Specifications
Product specifications for the IV-SAM-VXP-1B and IV-SAM-VXS-1B are provided below.
Product Specifications
Automate VX Pro Capabilities
Titles, Graphics, Layouts Titles, logos, backgrounds can be added, Easy-to-use graphic designer to create
any multi-source layout
Program Record MP4 file (H.264 codec). User-selectable bitrate up to 10 Mbps
ISO Record MJPEG MOV (30–200 Mbps) Individually selectable
Recording Capacity Records to internal 1TB SSD storage
Streaming Encoder Can stream to any RTMP server. Presets included for popular CDNs
NDI Support For inputs and program output
Camera Control Can control 1 Beyond PTZ cameras and tracking cameras (AutoTracker and
AutoFramer) over IP
System Control RESTful API over Network (TCP) for third party control
Compatible Codecs Output via HD-SDI (SDI to HDMI® converter included) for connection to
external conferencing codec or via USB adapter to external systems running
Microsoft Teams® software, Zoom Rooms™ software, etc.
Configuration Browser-based configuration with secure log-in and user administration
Connectivity
Network Ports 2x RJ-45 Gigabit Ethernet
Video
Video Inputs 7x HD-SDI Inputs;
Up to 12 cameras with NDI|HX® interface
Video Output Up to 1080p60 , 1x HD-SDI (SDI to HDMI® converter included);
NDI|HX
Desktop Output 4x DisplayPort™ output
Audio
Audio Input 3.5 mm Line In, USB, Dante® input
Compatible Mic
Systems
For a list of compatible mic systems, refer to OLH Article 1001562.
Compatible DSPs For a list of compatible DSPs, refer to OLH Article 1001563.
Power
